Technical specifications of SNS 7t:
• operating frequencies 2, 8, 12, 18, 24, 30 and 41 kHz;
• New working menu (selection of display menu layout);
• target drilling – automatic activation at the front point;
• measurement of interference to select the optimal frequency at a specific object;
• three probe power modes;
• * one probe (380x32 mm) with the ability to program one of seven frequencies and one of three modes;
• switching frequencies underground;
• working depth at maximum power up to 38m with wireless transmission;
• cable probe (480x32mm) – working depth up to 60m;
• operating time from 1 set of batteries at minimum power – 50 hours, at maximum – 10 hours;
• accuracy of the longitudinal angle of inclination 0.1 %;
• operating temperature range from -20 oC to +60 oC.
The warranty period for the system (not including the probe) is 12 months from the date of implementation, for the probe – 6 months. Post-warranty service.
